SFU 3210 Precision Ball Screw | 32mm Diameter | 3000mm Length
The SFU 3210 Precision Ball Screw is a high-performance linear drive component engineered for demanding industrial environments. With a robust 32mm shaft diameter and a high-lead 10mm pitch, this ball screw delivers an exceptional balance of high-load carrying capacity and rapid linear speed. The 3000mm length is precision-rolled from high-grade hardened steel, ensuring minimal deflection and surgical positioning accuracy over long travel distances. This unit features professional end-processing specifically machined to accommodate standard BK25/BF25 or BK20/BF20 support blocks, allowing for seamless integration into heavy-duty CNC router axes, industrial milling centers, and automated gantry systems. The SFU internal circulation design ensures low-friction movement, reduced thermal expansion, and long-term durability under high-duty cycles.
- Large 32mm diameter for superior rigidity and high load capacity
- High-lead 10mm pitch for increased linear travel speed
- Precision-ground end processing for BK25/BF25 and BK20/BF20 supports
- 3000mm continuous length for large-format machine axes
- Hardened bearing steel construction for maximum wear resistance
- Low-friction motion with zero-backlash potential
Comparative Technical Spindle Motor Configurations Matrix
Use the structural data catalog matrix below to evaluate power outputs, maximum RPM, operating voltages, and cooling styles across standard TriQuench CNC spindle models.
| Spindle Capacity | Operating Speed | Operating Voltage | Cooling System |
|---|---|---|---|
| 12.0 kW | 18,000 RPM | 380 V | Water-Cooled |
| 0.8 kW | 24,000 RPM | 220 V | Air-Cooled (Long Shaft) |
| 3.7 kW | 40,000 RPM | 380 V | Water-Cooled ISO20 |
| 9.0 kW | 18,000 RPM | 380 V | Air-Cooled |
Technical Specifications
| Technical Parameter | Engineering Specification Value |
|---|---|
| MODEL NUMBER | SFU 3210 |
| DIAMETER | 32 mm |
| PITCH_LEAD | 10 mm |
| TOTAL LENGTH | 3000 mm |
| MATERIAL | Hardened High-Grade Steel Alloy |
| MECHANICAL | precisionGrade: Industrial Precision Certified | supportCompatibility: BK25/BF25 or BK20/BF20 | threadDirection: Right Hand |
Industrial Applications
| Usage Scenario | Target Industry |
|---|---|
| Heavy-Duty Industrial CNC Routers | Machine Tool Manufacturing and CNC Fabrication |
| Large-Format Gantry Milling Machines | Industrial Automation and Robotics |
| Automated Bridge Saws and Stone Processing | Stone and Architectural Masonry Fabrication |
| High-Load Vertical Machine Tool Axes | Aerospace and Automotive Engineering |
| Industrial Robotics and Linear Actuators | Large-Scale Furniture Production |
| Precision Material Handling Systems | General Engineering |
Technical FAQ & Operational Guide
Is the SFU 3210 nut included with the screw?
Yes, our SFU 3210 3000mm assembly typically includes the high-precision ball nut. The nut features internal circulation and integrated dust seals to protect the ball tracks.
What is the benefit of the 32mm diameter over a 25mm screw?
The larger 32mm diameter significantly increases axial rigidity and prevents 'whipping' or vibration over the 3000mm span. This is essential for maintaining precision in heavy-duty machines where high cutting forces are present.
Does this come with the BK25/BF25 support blocks?
While the screw is pre-machined for these supports, the blocks themselves are usually sold separately to allow you to choose the bearing grade that best fits your application. We stock both standard and high-precision support block sets.
