HGW 15CC ZAC LM Block | High-Precision Flange Type Linear Carriage

The HGW 15CC ZAC is a premier Wide Flange (HGW) type linear motion carriage specifically designed for high-precision industrial environments. Engineered with a 'Heavy Load' (CC) configuration, this block provides exceptional rigidity and load distribution, making it the ideal choice for the primary axes of CNC routers and heavy-duty industrial machinery. It features a Z0 Pre-Tension setting to ensure smooth, zero-play motion while maintaining high stability during rapid travel. Constructed from premium-grade materials with stainless steel components, the HGW 15CC ensures superior corrosion resistance and an extended operational lifespan. The versatile carriage design includes four threaded holes for secure top-down mounting, with a machined recess that allows for bottom-up installation using a smaller bolt size, offering unmatched flexibility for custom machine builds.

Wide Flange (HGW) design for enhanced lateral stability
Heavy Load (CC) model optimized for high-rigidity applications
Z0 Pre-Tension setting for zero-play, high-precision motion
High Precision Class (H) accuracy for demanding industrial tasks
Stainless steel construction for superior durability and rust resistance
Dual-mode mounting: Top-down threaded or bottom-up bolt installation
Integrated self-lubrication tracks for reduced maintenance intervals

Engineering Analysis & Technical Data

Technical Parameter	Specification Details
MODEL NUMBER	HGW 15CC ZAC
BLOCK TYPE	Flange Type (Wide)
NOMINAL WIDTH	15 mm
LOAD TYPE	Heavy Load (CC)
PRE TENSION	Z0 Standard
PRECISION CLASS	H (High)
MECHANICAL	weight: 0.19 kg \| material: Stainless Steel / Bearing Steel \| protectionRating: Dust-Proof Seal Integrated

Industrial Applications

Usage Scenario	Target Industry
CNC Router X, Y, and Z Axis Support	Precision Machine Tool Manufacturing
Heavy Load Linear Rail Systems	Industrial Automation and Robotics
Precision Automated Assembly Lines	Furniture and Signage Fabrication
Industrial Laser and Plasma Cutting Machines	Aerospace and Automotive Engineering
Medical Instrumentation and Scanning Tables	Medical and Laboratory Technology
Packaging Machinery and Pick-and-Place Systems	General Engineering
High-Precision Measuring and Testing Equipment	General Engineering

Technical FAQ

What is the advantage of the Flange (HGW) type over a square block?

Flange type blocks provide a wider mounting surface and lower profile, which significantly improves lateral stability and makes them easier to mount from the top or bottom in heavy-duty CNC applications.

Does this block come pre-lubricated?

Yes, our HGW 15CC ZAC blocks are supplied with a factory-standard light oil coating for initial protection. However, we recommend applying a high-quality lithium-based grease through the grease nipple before active service.

What does Z0 Pre-Tension mean for my machine?

Z0 indicates a clearance-style pre-load that offers the smoothest movement with the least resistance. It is ideal for applications where precision is required but minimal friction is necessary to maintain high travel speeds.
