HGH 25CA BG LM Block | High-Precision Square Type Linear Carriage

The TriQuench HGH 25CA BG is a premier Square Type (HGH) linear motion carriage specifically designed for heavy-duty industrial environments. Engineered with a 'High Load' (CA) configuration, this block provides exceptional structural rigidity and optimized load distribution across its four rows of ball bearings. Its square profile allows for compact mounting in dense machinery setups while maintaining a high torque-resistant architecture, making it the ideal choice for the primary axes of large-format CNC routers, plasma cutters, and automated bridge saws. Manufactured from induction-hardened alloy steel, the HGH 25CA ensures smooth, low-friction travel and high repeatable precision even under extreme axial and radial stresses. With integrated dust protection and a high-performance lubrication system, this block is built for long-term reliability and minimal maintenance in 24/7 production cycles.

High-rigidity square design for superior structural stability
Four-row ball circulation for equal load capacity in all directions
Heavy Load (CA) rating optimized for high-demand CNC axes
Precision-ground raceways for ultra-smooth travel and low noise
Hardened alloy steel construction for extended wear resistance
Built-in wiper system for effective dust and debris protection
Standardized mounting for easy integration with HGR25 rails

Engineering Analysis & Technical Data

Technical Parameter	Specification Details
MODEL NUMBER	HGH 25CA BG
BLOCK TYPE	Square Type
NOMINAL WIDTH	25 mm
LOAD TYPE	High Load (CA)
PRE TENSION	Z0 / ZA Standard
ACCURACY GRADE	H (High) Precision
MECHANICAL	weight: 0.59 kg \| material: Induction-Hardened Alloy Steel \| protectionRating: Dual-Lip Dust Seal Integrated

Industrial Applications

Usage Scenario	Target Industry
Large-Format CNC Router Axes (X, Y, Z Support)	Precision Machine Tool Manufacturing
Industrial Bridge Saws and Stone Processing Machinery	Stone and Marble Processing Industry
Heavy-Duty Plasma, Waterjet, and Laser Cutting Beds	Furniture and Heavy Woodworking Fabrication
Automated Milling and CNC Machining Centers	Automotive and Aerospace Engineering
Precision X-Y Tables and Linear Positioning Stages	Industrial Robotics and Logistics
Industrial Robotics and Warehouse Automation Tracks	General Engineering
High-Precision Measurement and Inspection Equipment	General Engineering

Technical FAQ

What is the difference between HGH (Square) and HGW (Flange) blocks?

HGH blocks have a square, high-profile design with a narrower mounting surface, making them ideal for space-constrained or high-rigidity setups. HGW blocks have a wider flange mounting surface, which offers better lateral stability and allows for mounting from the top or bottom.

Does this block require specific rail compatibility?

Yes, the HGH 25CA BG is specifically designed to fit HGR25 series linear rails. Using TQI-branded rails is recommended to ensure the precision ball tracks align perfectly for optimal performance and life.

How often should I lubricate the HGH 25CA block?

For standard industrial use, we recommend re-greasing every 100km of travel or every 3 months. In high-debris environments like stone cutting or woodworking, more frequent maintenance intervals are required to clear internal contaminants.
